Different Truck Head For Different Work

Many customers say that from the picture appearance truck head are exactly the same, the price should be the same. However, it is impossible to judge the price only from the picture, there are many factors affecting the price of a truck, such as engine power, tyres, frame thickness and even shipping fee. Especially for tractor trucks, different chassis have a great influence on the price. Take the SINOTRUK HOWO tractor truck as an example, we will introduce you in detail the different chassis of tractor trucks, and the corresponding suitable working conditions.



1. Light Duty Truck Head.



a. Introduce: This model tractor truck with light duty chassis, it’s design for the light duty cargoes transport, such as container transportation work etc, total transport weight around 50 tons (truck head+semi trailer+cargoes). The chassis adopt the TGA tech, and axle is single diff, with 3 pcs leaf spring in each side of front axle and 5 pcs leaf spring in each side of rear axle. Front axle loading capacity is 7,000kg, rear axle loading capacity is 2x13,000kg. Due to only loading 35 tons cargoes, the saddle of truck head also use the light duty model, JOST brand 50#, 2 inch.



b. Suitable Countries: Now this light duty truck head is very popular in East Africa countries, such as Tanzania, Uganda, Mozambique, Zambia, Kenya etc. With lighter weight and very low fuel consumption, ideal for logistics companies.





2. Standard Truck Head.



a. Introduce: The standard truck head chassis is capable of transporting lightweight goods as well as standard goods such as various types of containers and bulk cargoes. It has a higher load capacity than the light duty truck head, which is capable of loading up to around 50 tonnes. The chassis adopt the TGA tech too, but each side of front axle have 3 pcs leaf spring and each side of rear axle have 12 pcs leaf spring . Front axle loading capacity is 7,000kg, rear axle loading capacity is 2x16,000kg. The saddle of truck head is adopt the SINOTRUK brand 90#, 3.5 inch model.



b. Suitable Countries: Now this model truck is very popular in Nigeria, Angola, Benin etc countries. Most of the customers in these countries use truck head for container transport in bad road condition, cause the axle with double diff when driving at bad road condition it have more stable and safety compare with single diff axle.





3. Heavy Duty Truck Head.



a. Introduce: Heavy duty truck heads are specially designed for heavy duty transport. These truck heads can transport more than 70 tonnes of cargo, making them ideal for transporting large goods over long distances. e.g. from mines to ports of embarkation or terminals. The truck chassis is 8+8+8mm thick, front axle loading capacity is 9500kg, read axle loading capacity is 2x16000kg, with double diff. And the front axle each side have 9 pcs leaf spring, rear axle each side have 12 pcs leaf spring. Due to always need heavy duty loading, so the saddle of truck head is adopt the heavy duty model, 3.5 inch.



b. Suitable Countries: The heavy duty truck head is very popular in some countries who have rich mineral resources, such as Mali, Ghana, Guinea, Dr Congo etc countries. They need to use the truck head to load a lot of cargo at once for long distance transport to get the minerals to the designated location. More and more customers are favouring the heavy duty truck head due to its high load capacity and sturdy chassis.
